minimum components for a
"RoboGuts™ Lesson Kit"






9V Battery cable 2.54mm connector pin spacing at least 10cm long



Qty. 1



Slide Switch (5mm x 10mm) Power Cable 2.54mm connector pin spacing at least 10cm long



Qty. 1



Cable for IR Receiver at least 10cm long



Qty. 1



Jumper Plugs 2.54mm spacing



Qty. 10



Jumpers wires 0.5mm diameter pins about 8cm to 10cm tip to tip
. . . . . . . . . . at least 5 of each color (Red, Green, Blue, White, Orange and Yellow)



Qty. 1



SYB-170 Mini Breadboard



Qty. 1



220 Ohm Resistors



Qty. 2



330 Ohm Resistors



Qty. 2



470 Ohm Resistors



Qty. 2



1K Ohm Resistors



Qty. 2



33µF 25V Capacitors



Qty. 2



Green LED



Qty. 1



Momentary Switch



Qty. 1



Light Dependent Resistor



Qty. 2



IR Receiver



Qty. 2



IR LED



Qty. 1



3-color RGB LEDs



Qty. 3



28mm to 32 mm .5W to 1W Speaker



Qty. 1



PIR Passive Infrared Sensor



Qty. 1



GP2Y0A41SK0F SHARP IR Infrared Range Sensor Module + Cable 4-30cm



Qty. 1




SG90 Servos SG-90 Mini Micro 9G Servo Motor for RC



Qty. 2




FEETECH FS90R Micro Continuous Rotation Servos



Qty. 2




DS18B20 Temperature Sensor



Qty. 1




BS170 BS170RLRAG MOSFET N-CHANNEL 60V 0.5A



Qty. 1




5V Active Piezo Electronic DC Buzzer Alarm Speaker for Arduino 85db



Qty. 1




HC-SR04 Ultra Sonic Sensor



Qty. 1



DC-Motors 5V DC



Qty. 2



L293D L293 Push-Pull Four-Channel Motor Driver IC DIP-16 NEW GM



Qty. 1



5V Geared Stepper Motor 28BYJ-48 with ULN2003 Driver



Qty. 1



Optional additions to the RoboGuts™ Kit




Cable for SRF05 UltraSonic Sensor



Qty. 1




Easy Driver Stepper Motor Driver



Qty. 1



Bipolar Stepper Motor with 150mm cable and 4-position header plug



Qty. 1




ADXL335 Module 3-axis Analog Output Accelerometer Angular Transducer GY-61



Qty. 1



PICAXE USB Download Cable

PICAXE USB Download Cable



Qty. 1



6pin 5V FTDI FT232RL USB TO TTL RS232 Serial Adapter Module Cable for Arduino



Qty. 1



Here's the round up list one of each excepet where noted;

9V Battery cable 2.54mm connector pin spacing Slide Switch (5mm x 10mm) Power Cable 2.54mm connector pin spacing

2.54mm spacing jumper plugs ... Need Ten

pkg of 65-Jumpers

220 Ohm Resistors

330 Ohm Resistors

470 Ohm Resistors

1K Ohm Resistors

33µF 25V Capacitors

Green LED

Momentary Switch

Light Dependent Resistor

IR Receiver

IR LED

3-color RGB LEDs ... Need Two

28mm to 32 mm .5W to 1W Speaker

PIR Passive Infrared Sensor

GP2Y0A41SK0F SHARP IR Infrared Range Sensor Module + Cable 4-30cm

SG90 Servos SG-90 Mini Micro 9G Servo Motor for RC ... Need Two

FEETECH FS90R Micro Continuous Rotation Servos ... Need Two

DS18B20 Temperature Sensor

BS170 BS170RLRAG MOSFET N-CHANNEL 60V 0.5A

5V Active Piezo Electronic DC Buzzer Alarm Speaker for Arduino 85db

ADXL335 Module 3-axis Analog Output Accelerometer Angular Transducer GY-61

HC-SR04 Ultra Sonic Sensor

DC-Motors 5V DC

L293D L293 Push-Pull Four-Channel Motor Driver IC DIP-16 NEW GM

Easy Driver Stepper Motor Driver

Nema 17 Stepper Motor Bipolar 59oz.in CNC/3D Printer Reprap Robot

5V Geared Stepper Motor 28BYJ-48 with ULN2003 Driver


Optional Programming Cables;

PICAXE USB Download Cable

6pin 5V FTDI FT232RL USB TO TTL RS232 Serial Adapter Module Cable
